Triple layer Forming Fabric For PRINT Paper

Name: Triple layer Forming Fabric For PRINT Paper
Brand: ATMC
Price: 1 USD

Brand Name : ATMC

MOQ : 1 pcs

Packaging Details : Standard export ply-wood case

Payment Terms : L/C，T/T

Pattern description : 2/6 Shed

Basis Weight (g/m²) : /

CMD Yarns Top : /

Air Permeability : 400-320 CFM 6320-5056m³ /m²h

Void Volume : /

Caliper (mm) New : 1.040

Fiber Support Index : 150-160

Paper Side Open Area : 33.1-30.4%

CMD Yarns Bottom : /

Fiber Support Point : 855-941 /cm²

Caliper (mm) Critical : /

Break Strength : ≥1000 N/cm

Structure : SSB Triple Layer

Fabric Color : Light Blue, Light Green

Price : inquiry

Supply Ability : Purchase supply

Drainage Index : 30.5-26.8

MD Yarns Top : /

MD Yarns Bottom : /

Elongation(50N/cm) : ≤0.45%

Contact Now

PRINT SSB57206W

The PRINT SSB57206W is a very fine plain weave paper side over six shaft wear side shute binding SSB triple layer design having a smooth sheet forming side with an open wear side that offers an excellent combination of sheet support, drainage capacity and wear capacity. The 3:2 paper side to wear side cross direction (CD) yarn ratio with high MD and CD stiffness for good wear potential and dimensional stability.

· Seam Type: Joined Endless

· Width: Up to 10.5 M

· Applications: Printing and Writing Papers

Triple layer Forming Fabric For PRINT Paper

Paper Side Wear Side
