Triple layer Forming Fabric For PRINT Paper

Name: Triple layer Forming Fabric For PRINT Paper
Brand: ATMC
Price: 1 USD

Brand Name : ATMC

MOQ : 1 pcs

Packaging Details : Standard export ply-wood case

Payment Terms : L/C，T/T

Price : inquiry

Supply Ability : Purchase supply

Contact Now

The PRINT SSB60210W is a fine plain weave paper side over ten shaft wear side shute binding SSB triple layer design having a smooth sheet forming side with an open, long float wear side that offers an excellent combination of sheet support, drainage capacity and wear potential. Both a high number of support points and a high FSI for lowest marking levels, clean run and excellent mechanical retention properties. The long wear side float with 3:2 forming to wear side cross direction (CD) yarn ratio allows the use of medium wear side CD yarns for improved life potential and excellent stability.

· Seam Type: Joined Endless

· Width: Up to 10.5 M

· Applications: Printing and Writing Papers, Top Layer of Multi-former, Board Grades

Features and benefits:

1. Two shed on paper side and ten shed on wear

side.

2. Even and fine paper side for even profiles.

3. Stable construction through two MD thread

systems and high CD stability.

4. Medium CD yarns with long float for exceptional

life potential.

5. Good fiber support for uniform formation.

6. Open structure for high dewatering and easy

showering

Triple layer Forming Fabric For PRINT Paper

Paper Side Wear Side
